Lower thermal conductivityTarget vs. mineral wool
Mineralised cellulose insulation
More Building. Less wall. More value.
Recycled cellulose. Engineered for thinner walls, more usable space and better project economics.
In development · TRL 2 · United States
Mineralised cellulose
Made to do more.
With less.
Development targets
Less material requiredModeled at equivalent thermal performance
Lower insulation material costModeled at equivalent thermal performance
Summer comfortModeled brochure scenarios
CO₂-neutral product target · A1/A2 fire-performance target · Three planned formats
The material
Built around the way you build.
Engineered performance
Lower thermal conductivity is our target. Thinner insulation is the opportunity.
Practical by design
Three planned formats for different construction and installation needs.
CO₂-neutral target
Recycled fibres and mineralised CO₂ form the basis of our footprint strategy.
$
Built to compete
Material efficiency and usable space connect performance to project value.
Performance visualised
Same thermal target.Less wall.
Move the slider to see how lower thermal conductivity can turn wall thickness into usable space inside a building.
Building movement is visually amplified for legibility; displayed values use Ecolation's 6.69 in modeled base thickness at the same target U-value. Final wall assemblies require certified product and project-specific data.
Product family
One material.Three ways to build.
One mineralised cellulose platform. Three planned formats, each with a different role.
Seamless application
Blow-in
Fast, seamless insulation for cavities and complex geometries—particularly suited to retrofit and existing buildings.
Walls · Roofs · CeilingsProduct concept visualization · Format in developmentFlexible format
Mats
Flexible insulation for timber-frame and standard construction systems, designed for precise fitting and easy handling.
Timber frame · Modular constructionProduct concept visualization · Format in development
Precision format
Boards
Soft to semi-rigid, non-structural boards for applications where defined formats support clean and consistent detailing.
Defined geometry · Easy handlingProduct concept visualization · Format in developmentThe process
From material to value.
From recycled fibres to a material platform designed to unlock space.
FIBRE
Recycled cellulose
Recycled paper fibres form the starting point.
Mineralisation
Mineral phases are designed to bind CO₂ and support stability.
Porous structure
A porous structure is designed to limit heat transfer.
m²
Project value
Thinner insulation can unlock usable floor area and material savings.
Current development statusTRL 2
Concept formulated. Product formats and performance figures remain development targets, not certified specifications.
123456789
What Technology Readiness Levels mean Project value calculator
What does betterinsulation unlock?
Test how insulation thickness, project geometry and material costs translate into usable floor area and commercial value.
ECOLATION.
Project Value ReportUS Metric · USD
Share or export the current calculation.
Project inputs
Enter project geometry and commercial assumptions.
Cooling benefit inputs
Results update instantly as inputs change.
Benchmark
Compare Ecolation with the brochure reference set.
Ecolation assumptions
- Thermal conductivity lambda
- 0.201 Btu·in/(h·ft²·°F)
- Material price
- $2.94/ft³
- Base thickness
- 6.69 in
Selected benchmark
- Material
- Stone wool
- Category
- Strategic reference
- Thermal conductivity lambda
- 0.263 Btu·in/(h·ft²·°F)
- Model material price
- $3.77/ft³
Model logic
- Wall thickness
- same thermal target
- Floor area
- perimeter × wall saving × storeys
- Material cost
- wall area × thickness × price
- Net project value
- sales gain + material cost saving
- Cooling benefits
- included and separately reported
Output summary
Decision-ready results in the selected unit system.
Net project value uplift+$141,064Sales value gain + material cost saving
Calculation preview
- Ecolation thickness
- 6.69 in
- Reference thickness
- 8.77 in
- Exterior wall area
- 11,302 ft²
- Ecolation material cost
- $18,564
- Reference material cost
- $31,108
- Peak cooling reduction
- 0.68 tons
- Annual electricity reduction
- 990 kWh/year
Methodology and source basisSee the formulas, assumptions and evidence status behind the model.View methodology
Equivalent wall thickness
Reference thickness = Ecolation thickness × reference λ ÷ Ecolation λ. Both assemblies are compared at the same target U-value.
Usable floor area
Additional floor area = building perimeter × saved wall thickness × number of storeys.
Material economics
Material cost = exterior wall area × insulation thickness × modeled material price.
Project value
Net project value uplift = additional sales value + material cost difference. Rent and the included cooling benefits are reported separately to avoid double counting.
Source basis
Ecolation Product Brochure and Project Value Calculator MVP.
Evidence status
Modeled planning estimate · Ecolation performance values are development targets.
Final verification
Requires certified data, project wall assemblies and project-specific energy simulation.
Illustrative planning model—not a quote, guarantee or certified building calculation. Final values require certified thermal data, project-specific wall assemblies, climate assumptions and dynamic building-energy simulation.
Sustainability
Performance and sustainabilityshould not be a trade-off.
Recycled inputs. Mineralised CO₂. A planned life beyond the building.
Early-stage concept & strategy
Co-developed with UNEP.
During a one-year phase, specialists from the UN Environment Programme accompanied Ecolation's early concept and strategy work. Their input helped integrate resource efficiency and circular thinking into the material concept, planned production route and business model.
Circular fibre backbone
Recycled cellulose forms the structural fibre network and creates a circular, widely available material base.
Mineralised functionality
Calcium carbonate phases are designed to support robustness, stability, moisture resilience and fire-performance potential.
Physical CO₂ storage
CO₂ is bound in mineral form within the insulation material as part of the mineralisation process.
Porous insulation structure
High porosity supports low heat transfer and practical blow-in applications across real construction projects.
Selected framework alignment
Aligned with
global goals.
Our development priorities connect to four UN Sustainable Development Goals.
Select a goal for more information from the United Nations.
Circular inputs
Long building life
Biochar pathway
Full
life cycle
life cycle
Beyond use
Designed with the full life cycle in mind.
Resource use, production logic, building performance and end-of-life pathways are considered as one connected system.
Circular inputs
Recycled paper fibres and industrial CO₂ become core raw materials rather than unused material streams.
Long-life performance
Mineralised functionality is designed to support robust, stable insulation for long-lived building applications.
End-of-life pathway
The material is designed for conversion into biochar through pyrolysis, extending carbon storage beyond the building's lifetime.
Digital transparency
Our goal is Digital Product Passport readiness with traceable composition, origin, performance and end-of-life data.
Team
Science, business, and scale.
An international team bringing together material science, technology strategy, finance, strategic capital and industrial execution.
Co-founder · CSODr. Abbas
Dr. Abbas
Beheshti Askari
Research & Development · Scientific Leadership
Read biography
Co-founder · CEODominik
Dominik
Thiel
Strategy · Business Development · Tech Oversight
Read biography
Co-founder · CFODr. Torsten
Dr. Torsten
Reiss
Finance · Investor Relations · Operations
Read biography
Co-founder · Head of Strategic CapitalFred
Fred
Dahl
Strategic Capital · Private Banking · Executive Leadership
Read biography
